Press Cold Extrusion KB0034

Sold

Specifications

ManufacturerBarnaul, Russia
ModelKB0034
ConditionUsed
Stock NumberMA1577
Item conditionGood condition
Capacity tons250

Description

Capacity : 250 tons,

Ram stroke : 200 mm,

Max. distance from : 28 mm,

Ram stroking rate : 40 c/mn,

Distance table /ram : 490 mm,

Ram adjustment : 16 mm,

Table area : 800 x 800 mm,

Lower ejector:

Stroke : 110 mm,

Capacity : 32 ton,

Upper ejector :

Stroke : 16 mm,

Capacity : 10 ton,

Main Motor power : 25 kW,

Dimensions : 2950 x 1950 mm,

Height over the floor : 4090 mm,

Air consumption per slide stroke : 0.00615 m3,

Oil centralized lubrication,

Overload security,

Weight : 21.5 tons.
