Press Trimming K9540
Specifications
Manufacturer | Abe Seiki,Japan |
Model | K9540 |
Year | 1974 |
Condition | Used |
Stock Number | MA1334 |
Item condition | Good Condition |
Capacity tons | 1000 |
Description
Capacity : 1000 tons,
Slider stroke length : 400 mm,
Unattainable-course : 12 mm,
Number of courses of a slider per minute : 20 rpm,
Number of single turn-on : 15 rpm,
The closed height : 730 mm,
Adjustment : 200 mm,
Under-forging plate :
From left to right : 1250 mm,
From front to rear : 1250 mm,
Thickness : 260 mm,
Slider overall dimensions : 1200 x 1460 mm,
Aperture in a table : 800 x 800 mm,
Window dimensions in cheeks : 1260 x 780 mm,
Course of a rigid pusher in a slider : 70 mm,
Force of a rigid pusher in a slider ton-force : 50,
Main electric motor power : 90 kW,
Course of pneumatic pillow : 160 mm,
Force of pushing out of a pneumatic pillow ton-force : 40,
Hydro-pneumatic pillow :
Working course : 125 mm,
Force of pushing out ton-force : 12,
Force of a clip ton-force : 125,
Press overall dimensions : 4310 x 3870 x 6790 mm,
Press weight : 77.1 tons.
