Press Hot Forging K8544

Sold

Specifications

ManufacturerAbe Seiki,Japan
ModelK8544
Year1976
ConditionUsed
Stock NumberMA1311
Item conditionVery good condition
Capacity tons2500

Description

Capacity : 2500 tons,

Ram Stroke : 350 mm,

Stroke per minutes : 60,

Shut height (ram down, table up) : 890 mm,

Table adjustment : 10 mm,

Distance between press columns : 1,320 mm,

Table dimensions (FB x LR) : 1,400 x 1,200 mm,

Ram dimensions (FB x LR) : 1,120 x 1,070 mm,

Mechanical upper ejector stroke : 0-60 mm,

Pneumatic lower ejector force : 10 ton,

Pneumatic lower ejector stroke : 70 mm,

Main motor power x rpm : 132 x 970 kW,

Press layout dimensions (FB x LR) : 4,680 x 5,350 mm,

Height above floor level : 6,400 (21 feet) mm,

Press weight : 190 tons.


The main motor power is 132 kWt.

Siemens controller 1200.

Schneider Electric variable frequency drive for the main motor.

The press is completely refurbished.

DeLimon centralized grease lubrication system with sensors controlling main lubrication blocks performance and separate table lubrication circuit.

Herion pneumatic system.


Design features of the press.


• Centralized grease lubrication.

• Motorized shut height adjustment built into the table. .

• Hydraulic nuts on tie rods that provide calibrated frame tightening and press un-jamming in a short

    time.

• The press has back shaft with built-in overload protectio

1976 Refurbished
