Hammer Drop Forging Open Die M1545
Sold
Specifications
Manufacturer | Abe Seiki,Japan |
Model | M1545 |
Year | 1981 |
Condition | Used |
Stock Number | MA0764 |
Item condition | Good Condition |
Capacity tons | 3.15 |
Description
Capacity : 3.15 tons,
Energy of striking : 8000 kJ,
Max. rate of striking : 56/min,
Max. working stroke of hammer : 1250 mm ,
Bearing distance between uprights : 4000 mm ,
Bearing distance between guidance : 630 mm ,
Ram dimensions : 600 х 340 mm ,
Vapour pressur
(of compressed air) : 0,6-0,7 Mpa,
Dimensions of hammer:
- in top view : 6450 x 2750 mm,
- heigth above floor level : 6300 mm,
Weight of hammer without anvil : 47.25 tons ,
Weight of anvil, approx.: 83.1 tons,
Technical manuals are available.
