Press Transfer Mechanical Manzoni Italy

Capacity : 630 tons,

Ram stroke – fixed : 350 mm

Stroke par minute : 15-35,

Number of Station : 4

Passage between stations : 380 mm

Height closed die : 850 mm

Height table feeder : 401 mm

Dimension table : 1850 x 1250 mm,

Dimension ram : 1850 x 1250 mm,

Front light columns : 1850 mm,

Lateral light columns : 1200 mm,

Distance max table-ram : 1200 mm,

Bars Opening Stroke : 105 mm,

Internal Light closed bars : 300–600 mm,

Internal Light open bars : 820 mm,

Max width coil : 500 mm,

No. Lower cushion : 4,

Max camme extraction sup : 210 mm.

with complete feeder Line brand SARONNI.

Coiler + Straightener + Electronic Feeder.
