Manipulator Zamet

Sold

Specifications

ManufacturerAbe Seiki,Japan
Year2008
ConditionUsed
Stock NumberMA0638
Item conditionGood Condition, dismantled & stored
Capacity tons50

Description

Rail Bound Forging Manipulator

Capacity : 50 ton,

Max Rds : 1700 mm,

Min Rds : 200 mm,

Max Sqr : 1500 mm,

Side Shift : 300 mm,

Clamping (Tongs) Moment :1250 kNm,

Min Parallel horiz position of tongs center above floor : 1100 mm,

Max Parallel horiz position of tongs center above : 3000 mm,

Vertical tilt of tongs - Up : 10º,

Vertical tilt of tongs - down : 7º,

Vertical stroke of tongs Parallel to Floor : 1350 mm,

Horizontal Slew Angle of Tongs : +/- 50 mm,

Rail Centers : 4200 mm,

Max turning circle of fully opened tongs : 3000 mm,

Peel rotation speed : 0-15 rpm,

Lifting and Lowering of Tongs complete stroke : 100 mm/sec.

New 2008.

Technical manuals available.
