Press Sheet Stamping Mechanical K3033B

Capacity : 200 tons,

Number of ram strokes per minute : 32,

Ram stroke : 320 mm,

Stroke path till its position where it develops nominal capacity : 8 mm,

Shut height : 500 mm,

Table size : 1250 x 2000 mm,

Bolster plate-to-ram adjustment stroke : 200 mm,

Bolster plate thickness : 160 mm,

Upper ejector capacity : 20 ton,

Upper ejector stroke : 100 mm,

Cushion capacity : 20 ton,

Cushion stroke : 90 mm,

Motor power : 18 kW,

Press dimensions : 3380 x 2400 x 5000 mm,

Press Weight : 22.5 tons.
