Gear Generator Spiral Bevel & Hypoid 463

Sold

Specifications

ManufacturerGleason, USA
Model463
ConditionUsed
Stock NumberMA0091
Item conditionGood Condition
Capacity tons0

Description

Max pitch diameter : 863 mm,

Max face width : 76 mm,

Cone distance (max. 30˚ spiral angle and 12" diameter wheel) - 15"/(381 mm)

Maximum pitch angle, shafts at 90˚ - 71˚ 34'

Minimum pitch angle, shafts at 90˚ - 5˚ 42'

Extreme ratio, shafts at 90˚ - 3 to 1

Maximum pitch diameter : (90˚ shafts):

Spiral angle 0˚, ratio 1 to 1 - 15.5"/(393.7 mm)

Spiral angle 0˚, ratio 3:1 - 23"/(584.2 mm)

Spiral angle 30 ˚, ratio 1:1 - 21"/(533.4 mm)

Spiral angle 30˚, ratio 3:1 - 31.5"/(800.1 mm)

Spiral angle 45˚, ratio 1:1 - 22.5"/(571.5 mm)

Spiral angle 45˚, ratio 3:1 - 34"/(863.6 mm)

Coarsest diametral pitch / metric module 2 DP / 12.7

Maximum face width 3"/(76.2 mm)

with full set of dressers, hydraulic chucking, guards, coolant.

Qty No : 4.
