Gear Shaper OHA32A Tos
Sold
Specifications
Manufacturer | Tos |
Model | OHA32A |
Condition | Used |
Stock Number | MA1995 |
Item condition | Good condition |
Capacity tons | 0 |
Description
Maximum Diameter : 320 mm,
Minimum Gear Diameter : 30 mm,
Maximum Module : 6 Module,
Maximum Angle of Tooth : 45,
Max & Min Number of Teeth : 300/6,
Table Diameter : 320 mm,
Table Bore : 110 mm,
Max. Gear Width : 70 mm,
Table drilling ø : 80 mm, depth 700 mm,
Length x width : 2150 x 1420 mm,
Machine height : 1980 mm,
Machine weight : 4.3 tons.
