Press Trimming KB9534
Specifications
| Manufacturer | TMP Voronezh Russia |
| Model | KB9534 |
| Year | 1982 |
| Condition | Used |
| Stock Number | MA1831 |
| Item condition | Good condition |
| Capacity tons | 250 |
Description
Capacity : 250 tons,
Ram stroke : 320 mm,
Ram continuous stroke number in minute : 32,
Ram single stroke number in minute : 24,
Ram size : 650 x 650 mm,
Table size : 800 x 800 mm,
Aperture in table : 500 x 500 mm,
Max distance between bolster and ram : 390 mm,
Adjustment : 140 mm,
Bolster size : 850 x 850,
Bolster thickness : 140 mm,
Main motor : 27 kW,
Dimensions :
Length : 3260 mm,
Width : 2970 mm,
Height : 5180 mm,
Machine weight : 25.8 tons.
