Press Sheet Stamping Hydraulic Ogihara

Sold

Specifications

ManufacturerAbe Seiki,Japan
Year1992
ConditionUsed
Stock NumberMA1632
Item conditionGood condition
Capacity tons800

Description

Capacity : 800 tons,

Upward capacity :80 tons,

Stroke : 1800 mm,

Daylight : 2300 mm,

Downward speed : 400 mm/sec,

Upward speed : 400 mm/sec,

Table : 3500 x 2300 mm,

Table Stroke : 3000 mm,

Table Speed : 100 mm/sec,


Die cushion

Capacity : 300 tons,

Cushion stroke : 300 mm,

Pad Size : 2650 x 1600 mm,

Upward speed : 80 mm/sec,

Downward speed : 80 mm/sec


Pumps

Main hydraulic pump : 270 kg/cm2 ,

Sub Pump : 170 kg/cm2,

Pilot Pump : 100 kg/cm2,


The press has a die cushion, and a front moving bolster.
