Press Hot Forging Erie

Sold

Specifications

ManufacturerAbe Seiki,Japan
ConditionUsed
Stock NumberMA1595
Item conditionVery good working condition
Capacity tons2500

Description

Capacity : 2500 tons,

Ram stroke : 350 mm,

Stroke per minute : 55 spm,

Main shaft diameter at journals : 575 mm,

Main shaft diameter at eccentric : 932 mm,

Width of eccntric bearing : 600 mm,

Shut height with top knockout plate : approx. 875 mm,

Shut height without top knockout plate : approx. 975 mm

Distance between the columns : 1212 mm,

Die seat (R-L x F-B) : 1212 x 1350 mm

Ram face (R-L x F-B) : 1100 x 1175 mm,

Lower knockout stroke : 125 mm,

Upper knockout stroke : 31.75 mm,

Floor space (R-L x F-B) : 3600 x 3050 mm,

Height above floor : 4375 mm,

Distance below floor : 700 mm,

Standard motor horsepower : 150 H.P.,

Approx. net weight : 140 tons,
